Textiles test |
COLOR FASTNESS TESTS |
1. Washing
1). Washing Temperature: 30*C/85*F - 60*C/140*F |
(1). ISO 105 CO1-C03 ISO 105 C06 Test A ?C |
--1. 30 minutes mechanical wash at 30*C/85*F |
--2. 45 minutes mechanical wash at 30*C/85*F |
(2). BS EN ISO 105 C06 Test A-C |
--1. 30 minutes mechanical wash at 30*C/85*F |
--2. 45 minutes mechanical wash at 30*C/85*F |
(3). BSEN 20105 C01-C03 |
--1. 30 minutes mechanical wash at 30*C/85*F |
--2. 45 minutes mechanical wash at 30*C/85*F |
(4). DIN EN 20105 C01-C03 |
--1. 30 minutes mechanical wash at 30*C/85*F |
--2. 45 minutes mechanical wash at 30*C/85*F |
(5). DIN EN ISO 105 C06 Test A-C |
--1. 30 minutes mechanical wash at 30*C/85*F |
--2. 45 minutes mechanical wash at 30*C/85*F |
(6). NF EN 20105 C01-C03 |
--1. 30 minutes mechanical wash at 30*C/85*F |
--2. 45 minutes mechanical wash at 30*C/85*F |
(7). NF EN ISO 105 C06 Test A-C |
--1. 30 minutes mechanical wash at 30*C/85*F |
--2. 45 minutes mechanical wash at 30*C/85*F |
(8). GB/T 3921.1-3 |
--1. 30 minutes mechanical wash at 30*C/85*F |
--2. 45 minutes mechanical wash at 30*C/85*F |
(9). GB/T 12490 Test A-C |
--1. 30 minutes mechanical wash at 30*C/85*F |
--2. 45 minutes mechanical wash at 30*C/85*F |
(10). AATCC 61 No. 1A, 2A |
--1. 30 minutes mechanical wash at 30*C/85*F |
--2. 45 minutes mechanical wash at 30*C/85*F |
(11). AS 2001.4.15 Test A-E |
--1. 30 minutes mechanical wash at 30*C/85*F |
--2. 45 minutes mechanical wash at 30*C/85*F |
2). Washing Temperature: above 60*C/140*F |
(1). |
--1. ISO 105 C04 ISO 105 C06 Test D |
--2. BS EN 20105 C04 |
--3. BS EN ISO 105 C06 Test D |
--4. DIN EN 20105 C04 |
--5. DIN EN ISO 105 CO6 Test D |
--6. NF EN 20105 C04 |
--7. NF EN ISO 105 C06 Test D |
--8. GB/T 3921.4 |
--9. GB/T 12490 Test D |
--10. AATCC 61 No. 3A-4A |
--11. AS 2001.4.15 Test F |
(2). |
--1. ISO 105 C05 ISO 105 C06 Test E |
--2. BSEN 20105 C05 |
--3. DIN EN 20105 C05 |
--4. BS EN ISO 105 C06 Test E |
--5. DIN EN ISO 105 C06 Test E |
--6. NF EN 20105 C05 |
--7. NF EN ISO 105 C06 Test E |
--8. GB/T 3921.5 |
--9. GB/T 12490 Test E |
--10. AS 2001.4.15 Test G |
3). Wash with bleach AATCC 61 No. 5A |
4). Wash with assessment on staining of solution |
|
2. Rubbing /Crocking
1). |
(1). ISO 105 X12 BS EN ISO 105 X12 |
(2). DIN EN ISO 105 X12 |
(3). AATCC 8 AS 2001.4.3 |
(4). CAN/CGSB -4.2 No. 22 (dry/wet ? water) |
(5). NF/EN ISO 105 X12 |
(6). GB/T 3920 AATCC 116 |
2). Additional wash cycle |
3). Additional dry clean cycle |
|
3. Perspiration
1). |
(1). ISO 105 E04 AATCC 15 |
(2). BS EN ISO 105 E04 |
(3). DIN EN ISO 105 E04 |
(4). AS 2001.4.17 |
(5). NF EN ISO 105 E04 |
(6). GB/T 3922 |
|
4. Drycleaning
1). |
(1). ISO 105 D01 AATCC 132 |
(2). BS EN ISO 105 D01 DIN EN ISO 105 D01 |
(3). AS 2001.4.16 |
(4). NF EN ISO 105 D01 GB/T 5711 |
2). With assessment on staining of solution |
|
5. Light
1). |
(1). ISO 105 B02 BS EN ISO 105 B02 |
--1. Grade 4 or below |
--2. Grade 5 |
--3. Grade 6 |
(2). DIN EN ISO 105 B02 |
--1. Grade 4 or below |
--2. Grade 5 |
--3. Grade 6 |
(3). NF EN ISO 105 B02 GB/T 8427 |
--1. Grade 4 or below |
--2. Grade 5 |
--3. Grade 6 |
2). AATCC 16E |
(1). 20 Fading units or below |
(2). 40 Fading units |
(3). 80 Fading units |
(4). 100 Fading units |
|
6. Water
1). |
(1). ISO 105 E01 BS EN ISO 105 E01 |
(2). AATCC 107 AS 2001.4.E01 |
(3). DIN EN ISO 105 E01 |
(4). NF EN ISO 105 E01 G/T 5713 |
|
7. Bleaching
1). Hypochlorite |
(1). ISO 105 N01 BS EN 20105 N01 |
(2). AS 2001.4.11 DIN EN 20105 N01 |
(3). NF EN ISO 105 No. 1 GB/T 7069 |
2). Peroxide |
(1). ISO 105 N02 AATCC 101 |
(2). BS EN ISO 105 N02 DIN EN ISO 105 N02 |
(3). NF EN ISO 105 N02 GB/T 7070 |
|
8. Chlorinated water
1). |
(1). ISO 105 E03 DIN EN ISO 105 E03 |
(2). BS EN ISO 105 E03 NF E ISO 105 E03 |
(3). GB/T 8433 |
2). AS 2001.4.5(per cycle) |
|
9. Chlorinated pool water
1). AATCC 162 AS/NZS 2001.4.5 |
|
10. Sea-water
1). |
(1). ISO 105 E02 BS EN ISO 105 E02 |
(2). DIN EN ISO 105 E02 NF EN ISO 105 E02 |
(3). AATCC 106 AS 2001.4.E02 |
(4). GB/T 5714 |
|
11. Acid spotting
1). ISO 105 E05 BS EN ISO 105 E05 |
2). DIN E ISO 105 E05 NF EN ISO 105 E05 |
|
12. Alkaline spotting
1). ISO 105 E06 BS EN ISO 105 E06 |
2). NF EN ISO 105 E06 DIN EN ISO 105 E06 |
|
13. Water spotting
1). ISO 105 E07 BE EN ISO 105 E07 |
2). DIN EN ISO 105 E07 NF EN ISO 105 E07 |
3). AS/NZS 2001.4.4 AATCC 104 |
|
14. Organic solvent
1). ISO 105 X05 BS EN ISO 105 X05 |
2). DIN EN ISO 105 X05 NF EN ISO 105 X05 |
|
|
DIMENSIONAL STABILITY (SHRINKAGE) AND RELATED TESTS (FABRIC & GARMENT) |
1. Dimensional stability to washing (washing shrinkage)
1). Washing temperature at 70*C/160*F or below |
(1). |
--1. BS EN 25077 / BS EN ISO 6330 |
--2. ISO 5077 / ISO 6330 |
--3. NF EN 25077 / NF EN ISO 6330 |
--4. DIN EN 25077 / DIN EN ISO 6330 |
--5. GB/T 8629 / GB/T 8630 |
--6. AS 2001.5.4 |
(2). Prolonged wash x 3 |
(3). Prolonged wash x 5 |
2). Washing temperature above 70*C/160*F |
(1). |
--1. ISO 6330 BS EN ISO 6330 |
--2. DIN EN ISO 6330 NF EN ISO 6330 |
--3. GB/T 8629 |
(2). Prolonged wash x 3 |
(3). Prolonged wash x 5 |
3). AATCC 135 washing temp. at 140*F or below (for fabric shrinkage) |
(1). 3 washes |
(2). 5 washes |
4). AATCC 150 washing temp. at 140 *F or below (for garment shrinkage) |
(1). 3 washes |
(2). 5 washes |
5). Garment test (report different measurement points) |
(1). Washing temperature at 70*C/160*F or below (per one wash) |
--1. Condition same as 1A(i) |
--2. Prolonged wash |
(2). Washing temperature above 70*C/160*F (per one wash) |
--1. Condition same as 1B(i) |
--2. Prolonged wash |
6). With appearance after actual laundering already conducted |
|
2. Each additional wash cycle
1). Wash only |
(1). For dimensional stability (shrinkage) |
(2). For colorfastness to actual laundering / appearance retention |
(3). Prolonged wash |
2). Wash with measurement |
(1). Fabric (cutting) |
(2). Garment |
(3). Prolonged wash |
3). Wash with visual assessment |
(1). Fabric/garment |
(2). Prolonged wash |
|
3. Appearance after laundering/ hand wash
1). ¼ûÏêϸ˵Ã÷ |
(1). Washing temperature at 70*C/160*F or |
--1. Condition same as 1A(i) |
--2. Prolonged wash |
(2). Washing temperature above 70*C/160*F (per one wash) |
--1. Condition same as 1B(i) |
--2. Prolonged wash |
2). Spirality only (per measurement) |
3). Visual assessment only |
4). Wash & Wear |
(1). Fabric |
--1. AATCC 124 ISO 7768 |
--2. GB/T 13769 |
(2). Seam |
--1. AATCC 88B ISO 7770 |
--2. GB/T 13771 |
(3). Crease |
--1. AATCC 88C ISO 7769 |
--2. GB/T 13770 |
(4). Garment |
--1. AATCC 143 |
|
4. Dimensional stability to commercial dry cleaning (drycleaning shrinkage)
|
5. Appearance after commercial drycleaning (appearance retention) |
6. Each additional commercial drycleaning cycle
1). Dryclean only |
(1). For dimensional stability test |
(2). For colorfastness/appearance retention test |
2). Dryclean with measurement |
(1). Fabric |
(2). Garment |
3). Dryclean with visual assessment |
|
7. Dimensional stability to free steam
|
|
STRENGTH TESTS |
1. Tensile strength
1). Grab/Cut strip test |
(1). One-inch grab |
(2). ISO 13934-2 AS 2001.2.3.2 |
(3). ASTM D 5034 CAN/CGSB -4.2 No. 9.2 |
(4). DIN EN ISO 13934-2 |
(5). BS EN ISO 13934-2 |
(6). NF EN ISO 13934-2 |
(7). GB/T 3923.2 |
2). Strip test |
(1). Two-inch cut strip |
(2). ISO 13934-1 ASTM D 5035 |
(3). AS 2001.2.3.1 CAN/CGSB -4.2 No. 9.1 |
(4). DIN EN ISO 13934-1 |
(5). BS EN ISO 13934-1 |
(6). NF EN ISO 13934-1 |
(7). GB/T 3923.1 |
3). Pre-wash required |
(1). With tensile strength test already conducted |
(2). Without tensile strength test conducted |
4). Elongation at break required |
|
2. Tear strength
1). Elmendorf |
(1). ASTM D 1424 AS 2001.2.8 |
(2). ISO 13937-1 |
(3). BS EN ISO 13937-1 DIN EN ISO 13937-1 |
(4). NF EN ISO 13937-1 GB/T 3917.1 |
2). Tongue |
(1). Single rip |
--1. ASTM D 2261 |
--2. ISO 13937-2 |
--3. BS EN ISO 13937-2 |
--4. DIN EN ISO 13937-2 |
--5. NF EN ISO 13937-2 GB/T 3917.2 |
(2). Double up |
--1. BS Handbook No. 11 |
--2. ISO 13937-4 EN ISO 13937-4 |
--3. DIN EN ISO 13937-4 |
--4. NF EN ISO 13937-4 |
(3). Wing-rip |
--1. ISO 13937-3 BE SEN ISO 13937-3 |
--2. DIN EN ISO 13937-3 |
--3. NF EN ISO 13937-3 |
(4). Trapezoid |
--1. ASTM D 5587 GB/T 3917.3 |
|
3. Bursting strength
1). Diaphragm bursting |
(1). ASTM D 3786 AS 2001.2.4 |
(2). ISO 13938 |
(3). BS EN ISO 13938 DIN EN ISO 13938 |
(4). NF EN ISO 13938 GB/T 7742 |
|
4. Seam properties
1). Strength |
(1). ISO 13935 BS EN ISO 13935 |
(2). DIN EN ISO 13935 NF EN ISO 13935 |
(3). GB/T 13773 ASTM D 1683 |
(4). AS 2001.2.20 |
(5). SO 6mm & Strength |
2). Slippage |
(1). BS 3320 ASTM D 434 |
(2). ISO 13936 BS EN ISO 13936 |
(3). DIN EN ISO 13936 NF EN ISO 13936 |
(4). GB/T 13772.1 |
(5). AS 2001.2.22/AS 2001.2.21 |
|
5. Bonding strength of laminated fabric
1). per one separation |
(1). AATCC 136 ASTM D 2724 |
(2). AS 1441.5 |
|
6. Single thread strength
1). per 20 readings |
(1). ASTM D 2256 GB/T 3916 |
(2). AS 2001.2.7 |
(3). ISO 2062 BS EN ISO 2062 |
(4). DIN EN ISO 2062 NF EN ISO 2062 |
|
|
FABRIC CONSTRUCTION TESTS |
1. Threads per unit length (woven fabric construction)
1). ISO 7211/2 ASTM D 3775 |
2). AS 2001.2.5 BS EN 1049.2 |
4). NF EN 1049-2 GB/T 4668 |
|
2. Stitch density (knitted fabric)
2). AS 2001.2.6 FZ/T 70002 |
|
3. Count of yarn
1). Woven fabric(2 readings of per yarn) |
(1). ASTM D 1059 ISO 7211/5 |
(2). each additional yarn |
2). Knitted fabric(per yarn) |
(1). ASTM D 1059 |
|
4. Fabric width
2). ASTM D 3774 AS 2001.2.12 |
|
5. Fabric weight
1). Per unit area |
(1). BS EN 12127 ISO 3801 |
(2). ASTM D 3776 (woven) |
(3). ASTM D 3887 (knit) |
(4). DIN EN 12127 NF EN 12127 |
(5). AS 2001.2.13 GB/T 4669 |
2). Per running yardage |
(1). BS EN 12127 ISO 3801 |
(2). ASTM D 3776 (woven) |
(3). ASTM D 3887 (knit) |
(4). DIN EN 12127 NF EN 12127 |
(5). AS 2001.2.13 |
(6). GB/T 4669 |
|
6. Fabric thickness
1). ISO 5084 BS EN ISO 5084 |
2). DIN EN ISO 5084 NF EN ISO 5084 |
|
|
COMPOSITION AND OTHER ANALUTICAN TESTS |
1. Fiber composition (Depend on fiber kinds)
1). Qualitative analysis |
(1). AATCC 20 |
--1. By simple identification method |
--2. Identification of natural fiber |
(2). BS 4407 |
--1. By simple identification method |
--2. Identification of natural fiber |
(3). ISO 1833 |
--1. By simple identification method |
--2. Identification of natural fiber |
(4). 96/73/EC |
--1. By simple identification method |
--2. Identification of natural fiber |
(5). GB/T 2910 |
--1. By simple identification method |
--2. Identification of natural fiber |
2). Quantitative analysis(composition in weight percentage) |
(1). AATCC 20A |
--1. By chemical and mechanical methods: components involving not more than 1 animal fiber/1 cellulosic natural fiber |
--2. By microscopic method: components involving more than 1 animal fiber/1 cellulosic natural fiber |
(2). BS 4407 |
--1. By chemical and mechanical methods: components involving not more than 1 animal fiber/1 cellulosic natural fiber |
--2. By microscopic method: components involving more than 1 animal fiber/1 cellulosic natural fiber |
(3). ISO 1833 |
--1. By chemical and mechanical methods: components involving not more than 1 animal fiber/1 cellulosic natural fiber |
--2. By microscopic method: components involving more than 1 animal fiber/1 cellulosic natural fiber |
(4). 96/73EC |
--1. By chemical and mechanical methods: components involving not more than 1 animal fiber/1 cellulosic natural fiber |
--2. By microscopic method: components involving more than 1 animal fiber/1 cellulosic natural fiber |
(5). GB/T 2911 |
--1. By chemical and mechanical methods: components involving not more than 1 animal fiber/1 cellulosic natural fiber |
--2. By microscopic method: components involving more than 1 animal fiber/1 cellulosic natural fiber |
(6). AS 2001.7 |
--1. By chemical and mechanical methods: components involving not more than 1 animal fiber/1 cellulosic natural fiber |
--2. By microscopic method: components involving more than 1 animal fiber/1 cellulosic natural fiber |
3). Garment composition analysis |
(1). fibre composition by weight percentage |
(2). plus garment dissection |
|
3. pH value
2). |
(1). AATCC 81 |
(2). BS EN 1413 |
(3). GB/T 7573 |
(4). ISO 3071 |
(5). DIN EN 1413 |
(6). NF EN 1413 |
|
4. Coated fabrics
1). Tensile Strength |
(1). ISO 1421 |
|
|
FLAMMABILITY TESTS |
1. Flammability of general clothing textiles
1). US CPSC 16 CFR Part 1610 |
|
2. Flammability of children¡¯s sleepwear
1). US CPSC CFR 16 Part 1615 |
(1). Flammability |
(2). 50 wash cycles |
2). US CPSC CFR 16 Part 1615 |
(1). Flammability |
(2). 50 wash cycles |
3). ASTM D6413 |
(1). Flammability |
(2). 50 wash cycles |
|
3. Leather tests
1). Colourfastness to rubbing |
(1). ISO 11640 |
(2). BS 1006 |
2). Tear strength |
(1). ASTMD 2212 |
(2). ASTM D4704 |
(3). BS3144 |
(4). ISO 3377 |
3). Leather thickness |
(1). ISO 2589 |
(2). EN ISO 2589 |
(3). BS 2589 |
(4). DIN 2589 |
|
|
FABRIC PERFORMANCE TESTS |
1. Abrasion resistance (Depend on rubbing times)
1). Martindale |
(1). ISO 12947 |
--1. First 10,000 rubs |
--2. Every other or part of 10,000 rubs |
--3. Shade change (after 10,000 rubs or below) |
(2). BS EN ISO 12947 |
--1. First 10,000 rubs |
--2. Every other or part of 10,000 rubs |
--3. Shade change (after 10,000 rubs or below) |
(3). DIN EN ISO 12947 |
--1. First 10,000 rubs |
--2. Every other or part of 10,000 rubs |
--3. Shade change (after 10,000 rubs or below) |
(4). NF EN ISO 12947 |
--1. First 10,000 rubs |
--2. Every other or part of 10,000 rubs |
--3. Shade change (after 10,000 rubs or below) |
(5). AS 2001.2.25 |
--1. First 10,000 rubs |
--2. Every other or part of 10,000 rubs |
--3. Shade change (after 10,000 rubs or below) |
(6). ASTM D 4966 |
--1. First 10,000 rubs |
--2. Every other or part of 10,000 rubs |
--3. Shade change (after 10,000 rubs or below) |
|
2. Pilling Resistance
1). I.C.I. pilling box (per 5 hours test) |
(1). GB/T 4802.3 |
(2). ISO 12945-1 |
(3). BS EN ISO 12945-1 |
(4). DIN EN ISO 12945-1 |
(5). NF EN ISO 12945-1 |
2). Random tumbler (per 30 minutes test) |
(1). ASTM D 3512 |
3). Martindale |
(1). GB/T 4802.2 |
(2). ISO 12945-2 |
(3). BS EN ISO 12945-2 |
(4). DIN EN ISO 12945-2 |
(5). NF EN ISO 12945-2 |
|
4. Water resistance (8 ordinary samples,Depend on coating¡¯s quality)
1). Hydrostatic pressure |
(1). ISO 811 |
--1. First 5,000 mm |
--2. Every other 5,000 mm |
(2). AATCC 127 |
--1. First 5,000 mm |
--2. Every other 5,000 mm |
(3). AS 2001.2.17 |
--1. First 5,000 mm |
--2. Every other 5,000 mm |
(4). BS EN 2011 |
--1. First 5,000 mm |
--2. Every other 5,000 mm |
(5). DIN EN 20811 |
--1. First 5,000 mm |
--2. Every other 5,000 mm |
(6). NF EN 20811 |
--1. First 5,000 mm |
--2. Every other 5,000 mm |
(7). GB/T 4744 |
--1. First 5,000 mm |
--2. Every other 5,000 mm |
|
5. Wrinkle recovery
1). Recovery angle method |
(1). AATCC 66 |
(2). ISO 2313 |
(3). BS EN 22313 |
(4). GB/T 3819 |
(5). DIN EN 22313 |
(6). NF EN 22313 |
|
6. Fabric stiffness
1). Cantilever Test |
(1). BS 3356 |
(2). ASTM D 1388 Option A |
(3). AS 2001.2.9 |
|
7. Stretch & recovery
1). |
(1). ASTM D 2594 (knitted fabric) |
(2). ASTM D 3107 (woven fabric) |
2). Elastic fabric |
(1). BS 4952 |
|
12. Water vapour permeability index
|
|
GARMENT ACCESSORY TESTS (LACE, ZIPPER, BUTTON, BUCKLE, ETC) |
2. Durability of zipper
1). Per 5,000 strokes (per test item) |
|
3. Operability of zipper
1). ASTM D 2062 (per test item) |
|
|
OTHER TEXTILE TESTS |
1. Garment size measurement
1). Against provided size specification (per 5 measurement points) |
|
2. Color difference assessment
1). Visual method (Each sample pair per lighting) |
|
|
ECO-TEXTILE TESTS |
1. Formalde-hyde content
1). Textile: Japanese Law 112 (JISL 1041) |
(1). GB/T 2912.1-1998 |
(2). GB/T 2912.2-1998 |
(3). ISO 14184-1:1998 |
(4). ISO 14184-2:1998 |
(5). AATCC 112:2003 |
(6). ¡ì35 B 82.02-1:1985 |
(7). BS 6806:2002 |
2). Leather |
(1). ISO/TS 17226:2003 |
|
2. PH Value
1). Textile |
(1). DIN 54275/6 |
(2). ISO 3071:2005 |
(3). GB/T 7573-2002 |
(4). EN 1413:1998 |
(5). AATCC 81:2001 |
2). Leather |
(1). ISO 4045:1977 |
|
3. Heavy metals content (10 elements)
|
6. Pesticides content\Organ chlorates\Organ phosphates\Parathyroid
|
7. Chlorinated phenols content (PCP, TeCP,)
1). Textile |
(1). GB/T 18414-2006 |
(2). ¡ì35 LMBG B 82.02-8:2001 |
2). Leather |
(1). SN0193.1-1993 |
(2). CEN/TS 14494:2003 |
(3). DIN 53313:1996 |
(4). ¡ì35 LMBG B 82.02-8:2001 |
|
9. Azo Dyes Content
1). Textile |
(1). 35 LMBG B82.02-2 |
(2). GB/T 17592.1-2006 |
(3). EN 14362-1-2003 |
2). Leather |
(1). 35LMBGB82.02-3:2004 |
(2). DIN 53316:1997 |
(3). ISO/TS 17234:2003 |
3). Polyester |
(1). 35LMBG B82.02-4 |
(2). EN 14362-2-2003 |
4). o-aminoazobenzene |
(1). ¡ì64 LFGB B 82.02-9:2006 |
|
10. Allergy causing dyes content (21 dyes included)
|
11. Carcinogenic dyes content (9 dyes included)
|
12. Chlorinated organic carrier content (10 compounds included)
|
13. Disperse Yellow 23 and Disperse Orange149
1). In-house method |
(1). DIN 54231:2005 |
|
14. Polychloro-benzen (PCB) (seven individual)
|
15. Flame retardant content (PBBs,Penta-,Ocata-BDE)
|
16. Phthalates (six individual)(DINP, DNOP, DEHP, BBP, DBP)
|
17. Polyamine hydrogen (PAH)
|
18. Organotins compounds (TBT,DBT,MBT)
|
19. Cr(VI)
1). Textile |
(1). GB/T 17593.3-2006 |
2). Leather |
(1). DIN 53314:1996 |
(2). EN 420:2003 |
(3). SN 0704-1997 |
3). Others |
(1). EPA 7196A |
|
20. Surfacatant,Alkyphenols and alkylphenol polyethoxylates(NPEO,OPEO,
|
21. Surfacatant (PFOS£¬PFOA)
|
22. Volatile Organic compounds (VOCs)
|
23. Odour Test
1). Screening |
(1). GB 18401-2003 |
(2). SNV 195651: 1968 |
|
|
MFD of WOOL TEXTILE and YARN(MICRO PROJECTION) |
1. MFD of WOOL TEXTILE and YARN(MICRO PROJECTION) |
|
|
